Lexus Toyota 230mm Carbon Twin Plate Clutch Kit Incl Flywheel 1670Nm

Lexus Toyota 230mm Carbon Twin Plate Clutch Kit Incl Flywheel 1670Nm
€2,518.42

The Xtreme 230mm Race Clutch is the ultimate in clutch solutions with a range like no other. The 230mm range boasts a variety of kits to suit most high horsepower applications for street, circuit, drift or race use.The Xtreme 230mm Race Clutch has been designed, allowing for endless options with clutch operation with internal hydraulic options and pull-push conversions a factoring feature in the 230mm range.

Product Features:

  • Push type billet alloy cover
  • Low pedal effort
  • 4140 Chromoly pressure & intermediate plates
  • Chromoly adapter ring
  • Low inertia
  • Carbon Friction Stable at extreme temperatures
  • Serviceable components
  • SFI certified design

Flat Diaphragm Rolled Diaphragm

Clamping Force                                                 1300kg           1300kg

Torque Rating                                                    1675Nm         1675Nm
Bearing Contact Diameter                               65mm      FLAT BEARING

Bearing Load (@ 48mm)                                  80kg                  150kg

Release Travel Required                                     7mm                  7mm
Assembly Mass (without flywheel)                   7.8kg                 7.8kg
