Garrett Turbocharger GT2560R Ball Bearing T25 .64 A/R 170-270HP 836023-5004S

€1,080.55

Note: Garrett has changed the part number on this turbo. The old part number is 466541-5004S and the new part number is 836023-5004S. Both old and new part numbers are exactly the same turbo with no differences.



Availability New: In Stock / Available

  • Barcode: 836023-5004S
  • Old Part Number: 466541-5004S
  • Shipping Weight (Dimensional): 20 lbs

General Information:

  • Part Type: Turbochargers
  • Make: Universal
  • Model: Universal
  • Engine: Universal
  • Brand: Garrett
  • Name: GT2560R

Technical Specifications:

  • Compressor Wheel Material: Cast
  • Compressor Wheel Inducer: 46mm
  • Turbo Horsepower Range: 0-250hp, 250hp - 500hp
  • Center Cartridge: Ball Bearing
  • Exhaust Housing Inlet: T25
  • Exhaust Housing Material: Cast Iron
  • Exhaust Wheel Exducer: 42mm
  • Exhaust Housing Outlet: 5 Bolt W/ Hole
  • Exhaust Housing AR: .64
  • Turbo Rotation: Standard Rotation

Additional Information: The Garrett GT2560R Turbocharger is a versatile and high-performance turbocharger suitable for a wide range of applications. With its cast compressor wheel and ball bearing center cartridge, it ensures durability and efficient performance. It supports horsepower ranges from 0 to 500hp, making it ideal for various tuning projects. The turbocharger features a T25 exhaust housing inlet and a 5 bolt exhaust housing outlet, providing ease of installation. It comes with a standard rotation and an exhaust housing AR of .64. Enjoy the convenience of free shipping with your purchase.


For more information or to place an order, please get in touch with us using your registered email address.
