Wiseco Piston Kit Mazda MX-5/Miata 1.6L 16V (-13cc) 8.5:1 Bore - Oversize 1.00 mm

€702.68

Wiseco pistons go through more finishing processes than any other piston on the market, without driving the cost up. They come with more features standard than any other piston on the market, at a more affordable price than many of the competitors. All of the Wiseco pistons for this application come standard with anti-friction skirt coating which helps minimize scuffing during break-in and lower friction on the cylinder wall. The top face of the piston is textured to improve the combustion characteristics, and all kits come with rings, pins and locks.


Our Sport Compact pistons are made from dedicated forgings produced in-house to give you a light weight piston with superior strength and optimal design. Being the multivalve piston technology leader, the line features specially designed valve pockets, complex dome and crown shapes, the steel nitride/napier xx rings and optimized skirt profiles. The pistons come standard with our ArmorGlide coating material for reduced friction and noise, freeing up horsepower.

Product specifications

Attribute Value
Bore - Actual 79.00 mm
Bore - Oversize 1.00 mm
Compression Height 31.95 mm
Compression Ratio - Actual 8.6:1
Country of Origin USA
Deck Clearance 0.18 mm
Dome Volume -13.0 cc
Material Type 2618
Piston Pin Diameter 20.00 mm
Ring Set Included 7900XX
Weight - Nominal 284 g

Compatible models

Mazda 1.6L 16v - B6 1950 9999
