Audi A4 TTE280L UPGRADE TURBOCHARGER VAG 1.8T
Introducing our TTE280L performance turbocharger for the 1.8T VAG longitudinal platform.
Engineered & Enhanced
To produce our hybrid K04 TTE280L upgrade turbocharger we use a much larger BorgWarner 2283 billet compressor wheel, chosen because it is highly efficient and features BorgWarner Extended tip technology, creating an extremely high flow for comparative size, but giving a compressor map that's very wide.
The intake to the compressor wheel is CNC milled billet and hand polished to smooth the transition from the intake pipework to the larger compressor to lower turbulence and maximize velocity.
Special profile 360 deg high-performance BorgWarner motorsport journal bearing is fitted, to remain durable at higher loads with no loss in transient response. The actuator used is uprated sprung BorgWarner unit.
Equilibrium
Precisely balancing our turbochargers is a key critical factor to become a TTE upgrade unit as longevity and performance are paramount. Good balance improves acoustics also. Subsequent great care is taken with all TTE turbochargers to achieving our balance standards. Firstly parts are balanced at slow speeds up to 2800RPM in multiple planes using our single parts machine, then components are assembled and then the CHRA are dynamically balanced, but this time depending on the application at up to 250,000 RPM in multiple planes using TTE in-house VSR machine to acquire the ultimate equilibrium, to a standard far higher than OEM. Each turbocharger is supplied with a serial numbered balance test result document.
Product Highlights
Original BorgWarner K03 turbocharger as the base part
BorgWarner Billet Milled compressor 6+6 BLADE 46.5mm inlet
BorgWarner TTE 9BLADE Larger High-Flow Turbine
BorgWarner actuator TTE upgraded
TTE Billet 58mm oversize intake (Viton O-rings Seals inc)
BorgWarner 360 ° Reinforced upgrade bearing system
Plug and Play installation with bigger turbo inlet hose (034 2.5" TURBO INLET customers do use)
300 PS Capable
Software recalibration is required
Proven TheTurboEngineers quality
Single parts finely balanced then components assembled and core high-speed VSR balanced
Supplied with a balance test result document
1 YEAR TTE TROUBLE-FREE WARRANTY
Made in Germany
